BMW X2 F39 (2017-2023) driver side external antenna Wiring diagram
This page shows the only wiring diagram for the component.driver side external antenna, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side external antenna (1 of 1)
ANTENNA SIG
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN/YEL WIRE
BUMPER ANTENNA
DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE
DRIVER SIDE EXTERNAL ANTENNA
ELECTRIC STEERING LOCK
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LED ACT
LIN BUS SIG
LUGGAGE COMPARTMENT ANTENNA
PASSENGER ELECTRONIC OUTER DOOR HANDLE MODULE
PASSENGER SIDE EXTERNAL ANTENNA
RED/YEL WIRE
RING ANTENNA
SIG
START SIG
START STOP
START-STOP BUTTON
TERMINAL 30
VIO/YEL WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Access/start circuit (2 of 2) -> DRIVER SIDE EXTERNAL ANTENNA
