BMW X2 F39 (2017-2023) charge air temperature boost pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.charge air temperature boost pressure sensor, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charge air temperature boost pressure sensor (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLOW OFF VALVE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CHARGE AIR TEMPERATURE BOOST PRESSURE SENSOR
CRANKCASE COOLANT SHUTOFF VALVE
DME MAIN RELAY
EXHAUST VANOS SOLENOID ACTUATOR
FUEL VENT VALVE
FUSE 1
FUSE 10
FUSE 11
FUSE 14
FUSE 18
FUSE 4
FUSE 5
FUSE 8
HEAT MANAGEMENT MODULE (LEFT SIDE OF ENGINE)
HOT AT ALL TIMES
HOT FILM AIR MASS METER
IGNITION, FUEL INJECTION RELAY
INTAKE VANOS SOLENOID ACTUATOR
INTEGRATED SUPPLY MODULE
KNOCK SENSOR
KNOCK SENSOR #2
OIL PRESSURE CONTROL VALVE
POWER SUPPLY SENSORS/ ACTUATORS RELAY
QUANTITY CONTROL VALVE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
TURBOCHARGER COOLANT PUMP
VALVETRONIC RELAY
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (3 of 6) -> CHARGE AIR TEMPERATURE BOOST PRESSURE SENSOR
