BMW X2 F39 (2017-2023) boot lid automatic soft-close drive Wiring diagram
This page shows the only wiring diagram for the component.boot lid automatic soft-close drive, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram boot lid automatic soft-close drive (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BODY DOMAIN CONTROLLER
BOOT LID AUTOMATIC SOFT-CLOSE DRIVE
BOOT LID/ TAILGATE LOCK
BRN WIRE
BRN/BLK WIRE
CENTER REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 11
FUSE 404
FUSE BOX
GRN WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL BI-STABLE RELAY ENERGIZED
LUGGAGE COMPARTMENT LAMP
NCA WIRE
ORG/ WIRE
OUTER TAILGATE BUTTON
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TRUNK LID LIFTING DRIVE
TAILGATE BUTTON
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Trunk & fuel door release circuit (2 of 2) -> BOOT LID AUTOMATIC SOFT-CLOSE DRIVE
