Blind spot monitoring circuit for BMW X1 U11/U12 (2022-2024)
Blind spot monitoring circuit
AUTONOMOUS DRIVING CAMERA LOW (ADCAML)
BASIC CENTRAL PLATFORM (BCP)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC)/ VIRTUAL INTEGRATION PLATFORM (VIP)
FRONT RADAR SENSOR (FRS)
FUSE 67
FUSE 69
FUSE 72
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
HOT W/
LEFT FRONT POWER DISTRIBUTION BOX
LEFT FRONT SIDE RADAR SENSOR SHORT RANGE (SRSNVL)
LEFT REAR RADAR SENSOR SHORT RANGE (HRSNL)
LIN POWER DISTRIBUTION BOX
RADOME HEATING
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SIDE RADAR SENSOR SHORT RANGE (SRSNVR)
RIGHT REAR RADAR SENSOR SHORT RANGE (HRSNR)
W/ FRONT RADAR SENSOR
W/O FRONT RADAR SENSOR
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
