BMW X1 F48 (2015-2019) outer door handle module wiring diagram
This page shows the only wiring diagram for the component.outer door handle module, which is found in the car BMW X1 F48 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
outer door handle module wiring diagram (1 of 1)
ALARM SYSTEM
ANTI-THEFT ALARM SYSTEM LED
BACKREST REMOTE UNLOCKING CONTROL ELECTRONICS
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE
DRIVER'S DOOR LOCK
DRIVER'S SIDE REAR DOOR LOCK
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR LOCK
FRONT POWER DISTRIBUTION BOX
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 94
GRN/BLK WIRE
GRN/BLU WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT W/ TERMINAL
K-CAN BUS SIG
LED ANTI-THEFT
LEFT BACKREST REMOTE UNLOCKING BUTTON
LEFT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
LIN BUS SIG
MIDDLE BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
OUTER DOOR HANDLE MODULE
PASSENGER ELECTRONIC
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT BACKREST REMOTE UNLOCKING BUTTON
RIGHT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
ROOF FUNCTION CENTER
SIREN W/ TILT ALARM SENSOR
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Anti-theft & central locking circuit (2 of 2) -> OUTER DOOR HANDLE MODULE
