BMW X1 F48 (2015-2019) electronics steering wheel module wiring diagram
This page shows the only wiring diagram for the component.electronics steering wheel module, which is found in the car BMW X1 F48 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
electronics steering wheel module wiring diagram (1 of 1)
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
ELECTRONICS JUNCTION BOX
ELECTRONICS STEERING WHEEL MODULE
FANFARE HORN RELAY
FRONT POWER DISTRIBUTION BOX
FUSE 13
FUSE 58
GRY WIRE
HIGH RANGE HORN
HORN BUTTON
HOT AT ALL TIMES
HOT W/
LEFT SHIFT PADDLE
LOW RANGE HORN
NCA WIRE
RED/BLK WIRE
RELAY ENERGIZED
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
VIO/BLU WIRE
VIO/YEL WIRE
Go to component -> Horn circuit -> ELECTRONICS STEERING WHEEL MODULE
