Trunk & fuel door release circuit for BMW X1 E84 facelift (2012-2015)
Trunk & fuel door release circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
CAR ACCESS SYSTEM (BEHIND RIGHT REAR QUARTERPANEL)
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUEL FILLER FLAP CENTER LOCKING DRIVE (RIGHT SIDE OF LUGGAGE COMPT)
FUSE
GRN WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INTERFERENCE SUPPRESSOR FILTER 2 (BEHIND RIGHT REAR QUARTERPANEL)
JUNCTION BOX (RIGHT END OF DASH)
ORG/GRN WIRE
REAR LID RELEASE SWITCH (INTERIOR)
RED WIRE
TRUNK LID BUTTON
TRUNK LID CENTRAL LOCKING DRIVE
WHT/BRN WIRE
