Lumbar circuit for BMW X1 E84 facelift (2012-2015)
Lumbar circuit
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT VACUUM PUMP
FUSE 20 BOX (RIGHT END OF DASH)
GRY WIRE
GRY/BLK WIRE
JUNCTION
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
PASSENGER'S SEAT VACUUM PUMP
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
SPORT SEATS CIRCUIT
VIO WIRE
