Heated steering wheel circuit for BMW X1 E84 facelift (2012-2015)
Heated steering wheel circuit
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
ELECTRONIC STEERING WHEEL MODULE (IN STEERING WHEEL)
GRN WIRE
GRN/RED WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED JUNCTION BOX FUSE 5 (RIGHT END OF DASH)
RED WIRE
STEERING COLUMN SWITCH CLUSTER
STEERING WHEEL HEATER SWITCH
STEERING WHEEL HEATING W/ TEMPERATURE SENSOR (IN STEERING WHEEL)
