Heated seats circuit, with memory for BMW X1 E84 facelift (2012-2015)
Heated seats circuit, with memory
BRN WIRE
CENTER CONSOLE SWITCH CENTER
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING ELEMENT
DRIVER'S SEAT CUSHION HEATING ELEMENT
DRIVERS SEAT MODULE (UNDER DRIVER SEAT)
ELECTRONICS JUNCTION BOX
FUSE 46
GRN WIRE
HEATING/ AIR CONDITIONING
JUNCTION BOX (RIGHT END OF DASH)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/BRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RELAY ENERGIZED FUSE 77
SYSTEM
YEL WIRE
