Horn circuit for BMW X1 E84 facelift (2012-2015)
Horn circuit
BLK WIRE
BRN WIRE
CAR ACCESS SYSTEM (BEHIND RIGHT REAR QUARTERPANEL)
ELECTRONICS JUNCTION BOX
FANFARE HORN RELAY
FUSE
FUSE 101 HOLDER (UNDER CENTER REAR OF LUGGAGE COMPT)
GRN WIRE
HORN SWITCH (IN STEERING WHEEL)
HOT AT ALL TIMES
JUNCTION BOX (RIGHT END OF DASH)
LEFT HORN (BEHIND LEFT END OF FRONT BUMPER)
REAR FUSE
RED WIRE
RIGHT HORN (BEHIND RIGHT END OF FRONT BUMPER)
STEERING COLUMN SWITCH CLUSTER
TERMINAL 15 RELAY
VIO/BLU WIRE
YEL WIRE
