Parking assistant circuit, w/o parking maneuvering assistant for BMW M6 F06/F13/F12 facelift (2015-2018)
Parking assistant circuit, w/o parking maneuvering assistant
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ELECTRONICS JUNCTION BOX
FUSE 504
FUSE BOX
GRN/BLK WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
JUNCTION BOX
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT OUTER ULTRASONIC SENSOR
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
RED WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT OUTER ULTRASONIC SENSOR
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
YEL WIRE
YEL/GRY WIRE
