BMW M6 F06/F13/F12 (2012-2015) wind deflector release power unit Wiring diagram

This page shows the only wiring diagram for the component.wind deflector release power unit, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wind deflector release power unit (1 of 1)

Wiring diagram wind deflector release power unit for BMW M6 F06/F13/F12 (2012-2015)

Get access

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BRN WIRE CONVERTIBLE TOP MODULE (CTM) (NEAR RIGHT "C" PILLAR) GRY/BLK WIRE GRY/GRN WIRE GRY/YEL WIRE LEFT FIN EXTENDED SENSOR (ON LEFT FIN HYDRAULIC CYLINDER) RED WIRE RIGHT FIN EXTENDED SENSOR (ON RIGHT FIN HYDRAULIC CYLINDER) WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE WIND DEFLECTOR RELEASE POWER UNIT YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component: -> Convertible top circuit (2 of 2) -> WIND DEFLECTOR RELEASE POWER UNIT
