BMW M6 F06/F13/F12 (2012-2015) trailer socket switch Wiring diagrams
This page contains all the electrical diagrams for the component. trailer socket switch, in which he is found in the car BMW M6 F06/F13/F12 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trailer socket switch (1 of 2)
Go to component -> Active bodyworks circuit, early production -> TRAILER SOCKET SWITCH
Wiring diagram trailer socket switch (2 of 2)
Go to component -> Active bodyworks circuit, late production -> TRAILER SOCKET SWITCH
