BMW M6 F06/F13/F12 (2012-2015) rear window roller sun blind drive Wiring diagram

This page shows the only wiring diagram for the component.rear window roller sun blind drive, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram rear window roller sun blind drive (1 of 1)

Wiring diagram rear window roller sun blind drive for BMW M6 F06/F13/F12 (2012-2015)

Get access

BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SWITCH BLOCK DRIVER'S DOOR W/ SEAT SWITCH BLOCK FOOTWELL MODULE (LEFT END OF DASH) FUSE 66 GRN WIRE HOT W/ TERMINAL JUNCTION BOX ELECTRONICS JUNCTION BOX ELECTRONICS (JBE) (UNDER RIGHT SIDE OF DASH) REAR WINDOW ROLLER SUN BLIND DRIVE RED/GRY WIRE WHT WIRE WHT/BRN WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Roller sun blind circuit -> REAR WINDOW ROLLER SUN BLIND DRIVE
