BMW M6 F06/F13/F12 (2012-2015) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car BMW M6 F06/F13/F12 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (31 of 72)

Wiring diagram nca for BMW M6 F06/F13/F12 (2012-2015)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 DEPTH ANGLE HEIGHT 1 2 3 4 SEAT BACKREST SIG TEMP SENS SEAT BACKREST 1 2 3 4 SEAT CUSHION 43 44 CAN 2 L CAN 2 H ACTUATOR MOTOR BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE BUS SIG BUS SIG BUS SIG PWR SPLY GND COMPUTER DATA LINES SYSTEM DRIVER'S SEAT DEPTH ADJUSTMENT DRIVE (W/ MULTI-FUNCTION SEAT) DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT) FOOTWELL MODULE (LEFT END OF DASH) FOR/BACK FUSE FUSE (UNDER RIGHT SIDE OF DASH) GRN WIRE GRN/BRN WIRE GRY/WHT WIRE GRY/YEL WIRE HALL SENSOR JUNCTION BOX NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BRN WIRE RED/WHT WIRE RELAY ENERGIZED SEATS SYSTEM SIG TEMP SENS SEAT CUSHION VIO/BRN WIRE W/O LUMBER SUPPORT W/ LUMBER SUPPORT WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Driver"s memory seat circuit (1 of 2) -> NCA WIRE

Wiring diagram nca (32 of 72)

Get access

BASIC, W/ VIDEO SWITCH BASIC, W/O VIDEO SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC NIGHT VISION MODULE (UNDER LEFT SIDE OF DASH) FUSE 124 (IN REAR POWER DISTRIBUTION BOX) GRN WIRE GRN/RED WIRE GRY WIRE HEAD UNIT HIGH W/ VIDEO SWITCH NCA WIRE NIGHT VISION CAMERA (BEHIND LEFT FRONT GRILLE) ORG/ WIRE REAR FUSE HOLDER RED WIRE RELAY ENERGIZED VIDEO SWITCH WHT WIRE YEL/WHT WIRE

Go to component: -> Electronic night vision circuit -> NCA WIRE

Wiring diagram nca (33 of 72)

Get access

ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COOLANT LEVEL SWITCH FUEL LEVEL SENSOR 1 FUEL LEVEL SENSOR 2 FUSE 10 FUSE 25 FUSE 26 GRN WIRE GRN/RED WIRE HEAD-UP DISPLAY HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL UNIT NCA WIRE ORG/ WIRE ORG/GRN WIRE OUTSIDE TEMPERATURE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED SENSOR (UNDER RIGHT HEADLIGHT ASSEMBLY) SOUND SYSTEMS YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component: -> Instrument cluster circuit -> NCA WIRE

Wiring diagram nca (34 of 72)

Get access

BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE CAMERA BASED DRIVER ASSISTANCE SYSTEMS (LEFT END OF DASH) CAMERA-BASED DRIVER SUPPORT SYSTEMS CAMERA HEATING COMPUTER DATA LINES SYSTEM DRIVER ASSISTANCE SYSTEMS OPERATING UNIT ELECTRONICS JUNCTION BOX FOOTWELL MODULE (LEFT END OF DASH) FUSE 13 FUSE 44 GRN WIRE GRY/GRN WIRE GRY/WHT WIRE HOT W/ BISTABLE RELAY ENERGIZED HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LANE DEPARTURE WARNING CAMERA (IN INSIDE REAR VIEW MIRROR ASSEMBLY) NCA WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/YEL WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE

Go to component: -> Lane departure warning circuit, with camera -> NCA WIRE

Wiring diagram nca (35 of 72)

Get access

BLU WIRE BLU/BRN WIRE BRN WIRE BRN/WHT WIRE BUS SIG BUS SIG FOOTWELL MODULE (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SWITCH BLOCK EXTERIOR MIRROR CAMERA FUSE 66 GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT EXTERIOR MIRROR NAVIGATION SYSTEM NCA WIRE ORG/ WIRE RED/GRY WIRE RELAY ENERGIZED RIGHT EXTERIOR MIRROR WHT/BRN WIRE WHT/BRN/YEL WIRE

Go to component: -> Memory mirrors circuit -> NCA WIRE

Wiring diagram nca (36 of 72)

Get access

ANTENNA DIVERSITY AUX-IN CONNECTION BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/YEL WIRE CENTRAL GATEWAY MODULE (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM COUPE DVD CHANGER FUSE 119 FUSE 120 FUSE 185 FUSE 29 GLOVE COMPARTMENT USB CONNECTION GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER DISTRI- BUTION SYSTEM REAR AERIAL REAR FUSE HOLDER (IN REAR POWER DISTRIBUTION BOX) REAR SEAT ENTERTAINMENT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE TOUCH BOX VIO/BRN WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, basic (1 of 2) -> NCA WIRE

Wiring diagram nca (37 of 72)

Get access

ALL ROUND VISION CAMERA BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM ELECTRIC VIDEO SWITCH NIGHT VISION MODULE (UNDER LEFT SIDE OF DASH) FRONT CENTER MID-RANGE SPEAKER FUSE FUSE 58 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE HEAD UNIT HIFI AMPLIFIER (LEFT REAR OF LUGGAGE COMPT) HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT FRONT WOOFER LEFT REAR RIGHT FRONT MID RANGE WOOFER SPEAKER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER VIO/BRN WIRE VIO/RED WIRE W/O VIDEO SWITCH, W/ ALL ROUND VISION CAMERA W/O VIDEO SWITCH, W/ W/ NIGHT VIDEO VISION SWITCH CAMERA WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, basic (2 of 2) -> NCA WIRE

Wiring diagram nca (38 of 72)

Get access

ANTENNA DIVERSITY AUX-IN CENTRAL GATEWAY CONNECTION MODULE (LEFT END OF DASH) BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPE DVD CHANGER FUSE 119 FUSE 120 FUSE 29 GLOVE COMPARTMENT USB CONNECTION GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL INTERIOR MOST DATA LIGHTS BUS CIRCUIT SYSTEM JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER DISTRI- BUTION SYSTEM REAR AERIAL REAR FUSE HOLDER (IN REAR POWER DISTRIBUTION BOX) REAR SEAT ENTER- TAINMENT CIRCUIT RED WIRE RED/BLK WIRE RED/WHT WIRE TOUCH BOX VIO/BRN WIRE VIO/RED WIRE W/ VIDEO MODULE, W/O SMART PHONE INTEGRATION W/ VIDEO MODULE, W/O SMART PHONE VIDEO INTEGRATION W/O VIDEO MODULE, (LEFT REAR OF LUGGAGE COMPT) SMART PHONE VIDEO INTEGRATION W/O VIDEO MODULE, SMART PHONE VIDEO INTEGRATION W/O VIDEO MODULE, W/ BASE PLATE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, high (1 of 3) -> NCA WIRE

Wiring diagram nca (39 of 72)

Get access

ALL ROUND VISION CAMERA BASE PLATE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM ELECTRONIC NIGHT VISION MODULE (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/YEL WIRE VIDEO SWITCH VIO/BRN WIRE VIO/RED WIRE W/ NIGHT VISION CAMERA W/ VIDEO MODULE, W/O SMART PHONE VIDEO INTEGRATION W/ VIDEO MODULE, W/O VIDEO SWITCH W/ VIDEO SWITCH W/O NIGHT VISION CAMERA W/O NIGHT VISION CAMERA, W/ BASE PLATE W/O NIGHT VISION CAMERA, W/ VIDEO MODULE W/O VIDEO MODULE W/O VIDEO SWITCH W/O VIDEO SWITCH, W/ ALL ROUND VISION CAMERA W/O VIDEO SWITCH, W/ BASE PLATE WHT WIRE WHT/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Navigation circuit, high (2 of 3) -> NCA WIRE

Wiring diagram nca (40 of 72)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 DEPTH TILT HEIGHT 1 2 3 4 SEAT BACKREST SIG TEMP SENS SEAT BACKREST 1 2 3 4 SEAT CUSHION 43 44 CAN 2 L CAN 2 H ACTUATOR MOTOR BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE BUS SIG BUS SIG BUS SIG PWR SPLY GND COMPUTER DATA LINES SYSTEM FOOTWELL MODULE (LEFT END OF DASH) FOR/BACK FUSE FUSE (UNDER RIGHT SIDE OF DASH) GRN WIRE GRN/BRN WIRE GRY/WHT WIRE GRY/YEL WIRE HALL SENSOR HALL SENSOR ACTUATOR MOTOR JUNCTION BOX NCA WIRE ORG/GRN WIRE PASSENGER'S SEAT DEPTH ADJUSTMENT DRIVE (W/ MULTI-FUNCTION SEAT) POWER DISTRIBUTION SYSTEM RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RELAY ENERGIZED SEATS SYSTEM SIG TEMP SENS SEAT CUSHION VIO/BRN WIRE W/O LUMBER SUPPORT W/ LUMBER SUPPORT WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Passenger"s memory seat circuit (1 of 2) -> NCA WIRE
