BMW M6 F06/F13/F12 (2012-2015) front center ventilation grille Wiring diagram
This page shows the only wiring diagram for the component.front center ventilation grille, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front center ventilation grille (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 VOLTAGE SUPPLY GND
AUC SENSOR
BLK WIRE
BLK/VIO WIRE
BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
BLOWER OUTPUT STAGE (ON BLOWER MOTOR)
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLANT PRESSURE SENSOR (TOP OF RIGHT FRONT WHEEL)
EARLY PRODUCTION
FRONT CENTER VENTILATION GRILLE
FUSE 11
FUSE 44
GND SUPPLY MIXING AIR CTRL
GRN WIRE
GRY WIRE
GRY/RED WIRE
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH)
HOT W/ BI-STABLE RELAY ENERGIZED
HOT W/ TERMINAL
IONIZER (ON HVAC UNIT)
JUNCTION BOX (UNDER RIGHT ELECTRONICS JUNCTION BOX SIDE OF DASH)
LEFT ADJUSTER SIG
LEFT STRATIFICATION ACTUATOR
LIN BUS SIG
LOCATOR LIGHTING
NCA WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component: -> Automatic a/c circuit (1 of 3) -> FRONT CENTER VENTILATION GRILLE
