BMW M6 F06/F13/F12 (2012-2015) fanfare horn button Wiring diagram

This page shows the only wiring diagram for the component.fanfare horn button, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram fanfare horn button (1 of 1)

Wiring diagram fanfare horn button for BMW M6 F06/F13/F12 (2012-2015)

Get access

BRN WIRE BRN/ORG WIRE BRN/VIO WIRE ELECTRONIC STEERING WHEEL MODULE (PART OF STEERING WHEEL) ELECTRONICS JUNCTION BOX FANFARE HORN BUTTON FUSE GRN/BLU WIRE HIGH HORN (RIGHT FRONT WHEELWELL) HORN RELAY HOT AT ALL TIMES FUSE BOX FUSE (INSTALLED ON BATTERY) HOT W/ JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LOW HORN (RIGHT FRONT WHEELWELL) RED WIRE RED/BRN WIRE RELAY RELAY ENERGIZED RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK STEERING COLUMN SWITCH CLUSTER TERMINAL VIO WIRE

Go to component: -> Horn circuit -> FANFARE HORN BUTTON
