BMW M6 F06/F13/F12 (2012-2015) central locking button operating unit hazard warning switch wiring diagram
This page shows the only wiring diagram for the component.central locking button operating unit hazard warning switch, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
central locking button operating unit hazard warning switch wiring diagram (1 of 1)
2 48 PWR SPLY AMBIENT LT
21 25 17 5 AMBIENT LT GROUND LIN BUS SIG GROUND
44 43 K-CAN BUS SIG K-CAN BUS SIG
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTER FRONT VENTILATION GRILLE
CENTRAL LOCKING BUTTON OPERATING UNIT HAZARD WARNING SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTION
CONVERTIBLE TOP CONTROL SWITCH
DVD CHANGER
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE (LEFT END OF DASH)
FRONT CIGARETTE LIGHTER
FUSE 1
FUSE 13
GRY/RED WIRE
HEATING/AIR CONDITIONING SYSTEM (CENTER OF DASH)
HOT W/ BISTABLE RELAY ENERGIZED
INTERIOR REAR LID BUTTON
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT FRONT VENTILATION GRILLE
LIGHT SWITCH UNIT
REAR SEAT ENTERTAINMENT
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT VENTILATION GRILLE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> CENTRAL LOCKING BUTTON OPERATING UNIT HAZARD WARNING SWITCH
