BMW M6 F06/F13/F12 (2012-2015) boot lid/ tailgate luggage compartment light Wiring diagram
This page shows the only wiring diagram for the component.boot lid/ tailgate luggage compartment light, which is found in the car BMW M6 F06/F13/F12 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram boot lid/ tailgate luggage compartment light (1 of 1)
BOOT LID/ TAILGATE LOCK
BOOT LID/ TAILGATE LUGGAGE COMPARTMENT LIGHT
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
FUSE 154 FUSE 153 (IN REAR POWER DISTRIBUTION BOX)
GRY/BLK WIRE
INTERIOR LIGHT)
LEFT FRONT VANITY MIRROR SWITCH
LEFT READING LIGHT
LUGGAGE COMPARTMENT LIGHT
REAR FUSE HOLDER
REAR LID CENTRAL ARMREST LEFT FRONT VANITY BUTTON MIRROR LIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT ENTRANCE LIGHT
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT READING LIGHT
ROOF FUNCTION MODULE
W/ BASIC VARIANT W/ HIGH VARIANT
WHT/BLK WIRE
Go to component: -> Courtesy lamps circuit, coupe (1 of 2) -> BOOT LID/ TAILGATE LUGGAGE COMPARTMENT LIGHT
