BMW M6 E63/E64 (2005-2010) steering body column gateway switch module cluster Wiring diagram
This page shows the only wiring diagram for the component.steering body column gateway switch module cluster, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering body column gateway switch module cluster (1 of 1)
ACTIVE SAFETY, STEERING GATEWAY MODULE
ALTERNATOR
ANTENNA ROLLOVER TUNER WITH PROTECTION CONTROLLER REMOTE CONTROL RECEIVER
BATTERY
BATTERY SENSOR (IN CENTER OF REAR COMPT)
BLK WIRE
BLU WIRE
CAR ACCESS SYSTEM
CONVERTIBLE CONVERTIBLE TOP TOP RELAY 1 RELAY 2
COOLER BOX
DME CONTROL MODULE
DME EDC CONTROL ELECTRONIC MODULE DAMPER CONTROL
DRIVER ACTIVE BACKREST WIDTH ADJUSTMENT
DRIVER'S
DYNAMIC DRIVE
DYNAMIC STABILITY CONTROL (DSC)
ELECTRONIC INTERIOR REAR-VIEW MIRROR
FROM FUSE 51 (DIAGRAM 1 OF 6)
FUEL FUEL PUMP PUMP RELAY OUTPUT STAGE
FUSE 50
FUSE 51
FUSE 54 FUSE 52
FUSE 58
FUSE 59 FUSE 60
FUSE 61
FUSE 62
GRN WIRE
GRY WIRE
HEADLIGHT WASHER RELAY
INTEGRATED SUPPLY MODULE (IVM)
JUMP
LEFT REAR DOOR MICROWAVE MICROWAVE SENSOR SENSOR
LOWERING REAR WINDOW RELAY (CONVERTIBLE)
NCA WIRE
OIL CONDITION SENSOR
PASSENGER'S ACTIVE INTEGRATED BACKREST SUPPLY WIDTH MODULE ADJUSTMENT (IVM)
PASSENGER'S DOOR MICROWAVE SENSOR
RAISING REAR WINDOW RELAY (CONVERTIBLE)
REAR DEFROSTER RELAY
REAR FUSE HOLDER (IN LUGGAGE COMPT)
REAR WIPER RELAY
RED WIRE
RED/GRN WIRE
RIGHT REAR MICROWAVE SENSOR
SEQUENTIAL MANUAL TRANSMISSION
SIREN, TILT ALARM SENSOR
STARTER
STEERING BODY COLUMN GATEWAY SWITCH MODULE CLUSTER
TERMINAL POINT
TO FUSE 52 (DIAGRAM 1 OF 6)
TO TERMINAL 15 RELAY (DIAGRAM 2 OF 6)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 6) -> STEERING BODY COLUMN GATEWAY SWITCH MODULE CLUSTER
