BMW M6 E63/E64 (2005-2010) obd ii socket Wiring diagram
This page shows the only wiring diagram for the component.obd ii socket, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram obd ii socket (1 of 1)
BASIC BODY MODULE
BLK WIRE
BLU WIRE
BODY-GATEWAY MODULE
BRN WIRE
CD CHANGER
CENTER CONSOLE SWITCH CENTER
COMFORT ACCESS CONTROL MODULE
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SEAT MODULE
DRIVER'S SIDE ELECTRONIC OUTSIDE MIRROR
DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE SMG TRANSMISSION
DVD CHANGER
DYNAMIC STABILITY CONTROL (DSC)
EDC ELECTRONIC DAMPER CONTROL
ELECTRIC VACUUM PUMP RELAY
ELECTRONIC DAMPER CONTROL POWER SAVING RELAY (IF EQUIPPED)
EXCEPT SEMI-ELECTRIC BASIC SEAT
FROM FUSE 17 DIAGRAM 5 OF 6)
FROM FUSE 25 DIAGRAM 6 OF 6)
FRONT FUSE HOLDER (BEHIND GLOVE BOX)
FUEL FUEL PUMP OUTPUT PUMP STAGE RELAY
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 29
FUSE 30
FUSE 31
FUSE 32
FUSE 33
FUSE 34 FUSE 35
FUSE 36
FUSE 37 FUSE 41
FUSE 38
FUSE 40
FUSE 42
GEAR INDICATOR LIGHTING
GRN WIRE
GRY WIRE
INDEPEDENT AUXILIARY HEATER (IF EQUIPPED)
INSTRUMENT TCU CLUSTER CONTROL MODULE
LEFT REAR ELECTRONIC OUTER DOOR HANDLE MODULE
NCA WIRE
OBD II SOCKET
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S SEAT MODULE
PASSENGER'S SIDE ELECTRONIC OUTSIDE MIRROR
RED WIRE
RIGHT REAR ELECTRONIC OUTER DOOR HANDLE MODULE
SEMI-ELECTRIC BASIC SEAT
STEERING COLUMN CLUSTER SWITCH
TERMINAL 15 LOAD SHEDDING RELAY
TO FUSE 26 DIAGRAM 6 OF 6)
USB EJECT HUB BOX
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> OBD II SOCKET
