BMW M6 E63/E64 (2005-2010) luggage compartment socket outlet Wiring diagram
This page shows the only wiring diagram for the component.luggage compartment socket outlet, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram luggage compartment socket outlet (1 of 1)
BASIC BODY MODULE
BLK WIRE
BLU WIRE
BRN WIRE
CAR ACCESS SYSTEM
COMPT)
ELECTRIC AUXILIARY HEATER
FLASHLIGHT CHARGING SOCKET
FROM FUSE 62 (DIAGRAM 1 OF 6)
FRONT CIGAR LIGHTER
FUSE 85 FUSE 87
FUSE 88
FUSE 90
FUSE 92 FUSE 91
GLOVE BOX CHARGING SOCKET
GRN WIRE
GRY WIRE
INTEGRATED SUPPLY MODULE (IVM)
LUGGAGE COMPARTMENT SOCKET OUTLET
REAR CIGARETTE LIGHTER
REAR FUSE HOLDER
REAR SOCKET OUTLET
RED WIRE
RELAY (DIAGRAM 3 OF 6)
SEQUENTIAL MANUAL TRANSMISSION (SMG)
SLIDE-IN COMPARTMENT
START-STOP BUTTON
TERMINAL 15 RELAY
TO FUSE 1 (DIAGRAM 5 OF 6)
TO TERMINAL
VALVE TIMING GEAR RELAY 1 (W/ REAR SEAT ENTERTAINMENT) INTERIOR LIGHTS SYSTEM
VALVE TIMING GEAR RELAY 2
WHT WIRE
Go to component: -> Power distribution circuit (2 of 6) -> LUGGAGE COMPARTMENT SOCKET OUTLET
