BMW M6 E63/E64 (2005-2010) left tank half fuel level sensor Wiring diagram

This page shows the only wiring diagram for the component.left tank half fuel level sensor, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left tank half fuel level sensor (1 of 1)

Wiring diagram left tank half fuel level sensor for BMW M6 E63/E64 (2005-2010)

Get access

BLK WIRE BLK/RED/YEL WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/BRN/YEL WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLK/WHT WIRE BRN/BLK/YEL WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTRIC FUEL PUMP ENGINE CONTROLS SYSTEM FUEL TANK GRN WIRE INSTRUMENT CLUSTER CONTROL MODULE LEFT TANK HALF FUEL LEVEL SENSOR RED WIRE RED/BLU WIRE VIO WIRE WHT WIRE YEL WIRE
