BMW M6 E63/E64 (2005-2010) left multifunction steering wheel switch block Wiring diagram

This page shows the only wiring diagram for the component.left multifunction steering wheel switch block, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left multifunction steering wheel switch block (1 of 1)

Wiring diagram left multifunction steering wheel switch block for BMW M6 E63/E64 (2005-2010)

Get access

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE DRIVER'S AIRBAG INFLATOR ASSEMBLIES (PART OF STEERING WHEEL) ELECTRONIC STEERING WHEEL MODULE (PART OF STEERING WHEEL) FRONT FUSE HOLDER (RIGHT SIDE OF DASH) GRN WIRE GRY WIRE HORN SWITCH HOT AT ALL TIMES LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK LEFT RIGHT ROCKER MULTIFUNCTION SWITCH STEERING WHEEL SWITCH BLOCK NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RIGHT ROCKER SWITCH STEERING COLUMN SWITCH CLUSTER VIO WIRE WHT WIRE

Go to component: -> Steering wheel control switch circuit -> LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK
