BMW M6 E63/E64 (2005-2010) driver's door automatic soft-close drive Wiring diagram
This page shows the only wiring diagram for the component.driver's door automatic soft-close drive, which is found in the car BMW M6 E63/E64 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door automatic soft-close drive (1 of 1)
ACTIVE CRUISE CONTROL
BLK WIRE
BLU WIRE
BRN WIRE
CENTER CONSOLE SWITCH CENTER
COUPE CONVERTIBLE
DIGITAL VIDEO TUNER MODULE
DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE
DRIVER'S SEAT ADJUSTMENT SWITCH
FAR RANGE SENSOR
FROM 68 (DIAGRAM 3 OF 6)
FROM CAR ACCESS SYSTEM (DIAGRAM 2 OF 6)
FROM TERMINAL 15 RELAY (DIAGRAM 2 OF 6)
FUEL PUMP RELAY
FUSE
FUSE 55
FUSE 68
FUSE 75
FUSE FUSE
GRN WIRE
GRY WIRE
HEATING/ AIR CONDITIONING SYSTEM
HEATING/AIR CONDITIONING SYSTEM
HIFI CENTER AMPLIFIER CONSOLE SWITCH
LEFT REAR AUTOMATIC SOFT-CLOSE DRIVE
PANORAMA CONVERTIBLE GLASS TOP ROOF MODULE
PARK DISTANCE CONTROL (PDC)
PASSENGER ACTIVE BACKREST WIDTH ADJUSTMENT
PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE
PASSENGER'S SEAT ADJUSTMENT SWITCH
RAIN/ HEADLIGHT SENSOR
REAR FUSE HOLDER (IN LUGGAGE COMPT)
RED WIRE
RIGHT LEFT CLOSE CLOSE RANGE RANGE SENSOR SENSOR
RIGHT REAR AUTOMATIC SOFT-CLOSE DRIVE
SATELLITE RECEIVER
TERMINAL
TO FUSE
TO FUSE 76 (DIAGRAM 4 OF 6)
TRUNK LID LIFT
VIO WIRE
WHT WIRE
Go to component: -> Power distribution circuit (3 of 6) -> DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE
