Power top/sunroof circuit for BMW M5 F90 facelift (2020-2024)
Power top/sunroof circuit
BLU WIRE
BRN/BLK WIRE
FUSE 27
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
RED/BLU WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
ROOF FUNCTION CENTER
SLIDE/ TILT SUNROOF SWITCH
SLIDE/TILT SUNROOF DRIVE UNIT (CENTER FRONT OF ROOF)
SUNROOF SHADE DRIVE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
