Lane departure warning circuit, w/ camera for BMW M5 F90 facelift (2020-2024)
Lane departure warning circuit, w/ camera
AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL
BLU/GRN WIRE
BODY DOMAIN CONTROLLER
BRN/BLK WIRE
BRN/YEL WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
ETHERNET SWITCH
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 10
FUSE 90
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
HOT W/
HOT W/ BI-STABLE RELAY ENERGIZED
KAFAS CAMERA HEATING
LANE CHANGE WARNING LED
MIRROR ELECTRONICS
NCA WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
STEERING COLUMN SWITCH CLUSTER
W/ ETHERNET SWITCH
W/O ETHERNET SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/BRN/YEL WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
