Contact-free tailgate opening circuit for BMW M5 F10 facelift (2013-2016)
Contact-free tailgate opening circuit
35 26 K-CAN BUS SIG K-CAN BUS SIG
AERIAL SIG AERIAL SIG
BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BUMPER AERIAL
CAR ACCESS SYSTEM (LOWER LEFT CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
ELECTRONIC JUNCTION BOX
FUSE 2
HOT W/ BISTABLE RELAY ENERGIZED
JUNCTION BOX (RIGHT SIDE OF DASH)
RED WIRE
W/ NON-CONTACTING TAILGATE CLOSING
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
