Car Wiring Diagrams for Charging circuit for BMW M5 F10 facelift (2013-2016)

ALTERNATOR BATTERY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT) ENGINE CONTROLS SYSTEM FUSE FUSE BOX (UNDER N/A SPARE TIRE) GRN/RED WIRE INTELLIGENT BATTERY SENSOR (BELOW RIGHT SIDE LUGGAGE COMPT) JUMP START TERMINAL POINT (LEFT SIDE OF ENGINE COMPT) NCA WIRE RADIATOR SHUTTER DRIVE UNIT RED WIRE SAFETY BATTERY TERMINAL GENERATOR (RIGHT SIDE OF REAR COMPT) STARTER TRANSFER TERMINAL POINT VIO WIRE
