Power top/sunroof circuit for BMW M5 F10 facelift (2013-2016)
Power top/sunroof circuit
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 58
FUSE 61
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/
JUNCTION BOX (RIGHT SIDE OF DASH)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
ROOF FUNCTION CENTER
SLIDE/TILT SUNROOF DRIVE UNIT
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
