Passenger power seat circuit for BMW M5 F10 facelift (2013-2016)
Passenger power seat circuit
ANGLE
BACK
BACK FRONT
BACK FRONT FRONT
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 53
FWD/BWD
GRN WIRE
GRY WIRE
HEADREST
HEIGHT
JUNCTION BOX (RIGHT SIDE OF DASH)
PASSENGER'S SEAT HEADREST HEIGHT ADJUSTMENT DRIVE
PASSENGER'S SEAT HEIGHT ADJUSTMENT DRIVE (UNDER FRONT PASSENGER'S SEAT)
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
TILT
VIO WIRE
WHT WIRE
YEL WIRE
