Front lumbar circuit, without memory for BMW M5 F10 facelift (2013-2016)
Front lumbar circuit, without memory
BLK/BLU WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK (DRIVER'S SEATBACK)
DRIVER'S SEAT LUMBAR SUPPORT DRIVE (UNDER DRIVER'S SEAT)
FUSE 67
JUNCTION BOX (RIGHT SIDE OF DASH)
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK (PASSENGER'S SEATBACK)
PASSENGER'S SEAT LUMBAR SUPPORT DRIVE (UNDER FRONT PASSENGER'S SEAT)
RED WIRE
RELAY ENERGIZED
VALVE 1
VALVE 2
VALVE 3
VALVE 4
