Lane departure warning circuit, with camera for BMW M5 F10 facelift (2013-2016)
Lane departure warning circuit, with camera
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
CAMERA BASED DRIVER ASSISTANCE SYSTEMS (LEFT END OF DASH)
CAMERA-BASED DRIVER SUPPORT SYSTEMS HEATING (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEMS OPERATING UNIT
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE (LEFT KICK PANEL)
FUSE 13
FUSE 44
GRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT W/ BISTABLE RELAY ENERGIZED
HOT W/ TERMINAL
JUNCTION BOX (RIGHT SIDE OF DASH)
LANE DEPARTURE WARNING CAMERA (BASE OF INTERIOR REARVIEW MIRROR ASSEMBLY)
NCA WIRE
ORG/ WIRE
RED WIRE
RED/YEL WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/WHT WIRE
