Independent heating circuit for BMW M5 F10 facelift (2013-2016)
Independent heating circuit
BLK/RED WIRE
BRN WIRE
ELECTRONICS JUNCTION BOX
FUSE 65
HOT W/ TERMINAL
INDEPENDENT AUXILIARY HEATER (BEHIND LEFT FRONT WHEEL)
INDEPENDENT HEATER CIRCULATION PUMP (BEHIND LEFT FRONT WHEEL)
INDEPENDENT HEATER COMBUSTION AIR BLOWER (BEHIND LEFT FRONT WHEEL)
INDEPENDENT HEATER PLUG (BEHIND LEFT FRONT WHEEL)
INDEPENDENT HEATING COOLING CHANGEOVER VALVE (BEHIND LEFT FRONT WHEEL)
INDEPENDENT HEATING FUEL METERING PUMP (BEHIND LEFT FRONT WHEEL HOUSING)
JUNCTION BOX (RIGHT SIDE OF DASH)
NCA WIRE
RED/VIO WIRE
WHT/BRN WIRE
