BMW M5 F10 facelift (2013-2016) w/ engine independent heating element Wiring diagram

A/C COMPRESSOR (ELECTRICAL) (HYBRID) (LOWER LEFT FRONT OF ENGINE) A/C COMPRESSOR (EXCEPT HYBRID) (LOWER LEFT FRONT OF ENGINE) AUXILIARY WATER PUMP (LEFT FRONT OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER OUTPUT STAGE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL VALVE DEFROSTER FLAP MOTOR (TOP LEFT SIDE OF DASH) DRIVER SIDE HEAT EXCHANGER WATER VALVE ELECTRIC- MACHINE ELECTRONICS FRESH AIR FLAP MOTOR FRONT PASSENGER'S HEAT EXCHANGER WATER VALVE HOT AT ALL TIMES JUNCTION BOX FUSE 71 (RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT FRONT FOOTWELL FLAP MOTOR (TOP LEFT SIDE OF DASH) LEFT FRONT STRATIFICATION FLAP MOTOR LEFT OUTER VENTILATION FLAP MOTOR LEFT REAR COMPARTMENT FOOTWELL FLAP MOTOR LEFT REAR STRATIFYING AIR FLAP MOTOR MAGNETIC CLUTCH NCA WIRE RECIRCULATED AIR FLAP MOTOR RED WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FOOTWELL FLAP MOTOR (TOP RIGHT SIDE OF DASH) RIGHT FRONT STRATIFICATION FLAP MOTOR RIGHT OUTER VENTILATION FLAP MOTOR RIGHT REAR COMPARTMENT FOOTWELL FLAP MOTOR RIGHT REAR STRATIFYING AIR FLAP MOTOR VIO WIRE VIO/BLK WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE W/ ENGINE INDEPENDENT HEATING ELEMENT W/O TWIN-CLUTCH GEAR BOX WATER VALVE ASSEMBLY (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/BRN/YEL WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE XDRIVE: REAR OF ENGINE BLOCK) YEL/BRN WIRE YEL/RED WIRE YEL/VIO WIRE
