BMW M5 F10 facelift (2013-2016) rear compartment automatic Wiring diagram
This page shows the only wiring diagram for the component.rear compartment automatic, which is found in the car BMW M5 F10 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear compartment automatic (1 of 1)
AUC SENSOR (ON AIR RECIRCULATION CONTROL MICROFILTER
AUTOMATIC CLIMATE CONTROL)
BRN WIRE
BRN/BLK WIRE
CENTRAL GATEWAY MODULE
CLIMATE CONTROL (IF EQUIPPED)
COMPT)
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUSE
FUSE 187 HOLDER (RIGHT SIDE OF REAR COMPT)
FUSE 188
GRN WIRE
HEATING SWITCH (W/O REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL)
JUNCTION BOX (RIGHT SIDE OF DASH)
NCA WIRE
ORG/GRN WIRE
REAR COMPARTMENT AUTOMATIC
REAR DRIVER'S SIDE SEAT BACKREST HEATING ELEMENT (IN LEFT REAR SEAT BACKREST)
REAR DRIVER'S SIDE SEAT CUSHION HEATING ELEMENT (IN LEFT REAR SEAT CUSHION)
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR DRIVER'S SIDE SEAT HEATING SWITCH (W/O REAR COMPARTMENT
REAR FUSE
REAR PASSENGER'S SIDE SEAT
REAR PASSENGER'S SIDE SEAT CUSHION HEATING ELEMENT (IN RIGHT REAR SEAT CUSHION)
REAR PASSENGER'S SIDE SEAT HEATING MODULE
RED/BRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Rear heated seats circuit -> REAR COMPARTMENT AUTOMATIC
