BMW M5 F10 facelift (2013-2016) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car BMW M5 F10 facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (71 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (71 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CENTER CONSOLE OPERATING UNIT COMPUTER DATA LINES SYSTEM DOUBLE CLUTCH TRANSMISSION FUSE 63 GEAR SELECTOR SWITCH GRN WIRE GRN/RED WIRE GRY/RED WIRE HOT W/ TERMINAL INTEGRATED CHASSIS MANAGEMENT (UNDER CENTER CONSOLE) JUNCTION BOX FUSE 64 (RIGHT SIDE OF DASH) LEFT SHIFT PADDLE NCA WIRE PARKING LOCK HOLDING MAGNET (UNDER FRONT OF CENTER CONSOLE) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT SHIFT PADDLE STEERING COLUMN SWITCH CLUSTER VIO/BLK WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

Go to component -> A/t circuit -> NCA WIRE

Wiring diagram nca (72 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (72 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

ALTERNATOR BATTERY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT) ENGINE CONTROLS SYSTEM FUSE FUSE BOX (UNDER N/A SPARE TIRE) GRN/RED WIRE INTELLIGENT BATTERY SENSOR (BELOW RIGHT SIDE LUGGAGE COMPT) JUMP START TERMINAL POINT (LEFT SIDE OF ENGINE COMPT) NCA WIRE RADIATOR SHUTTER DRIVE UNIT RED WIRE SAFETY BATTERY TERMINAL GENERATOR (RIGHT SIDE OF REAR COMPT) STARTER TRANSFER TERMINAL POINT VIO WIRE

Go to component -> Charging circuit -> NCA WIRE

Wiring diagram nca (73 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (73 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE GRN/RED WIRE HOT AT ALL TIMES HOT W/ NCA WIRE OIL TEMPERATURE SENSOR PNK/RED WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE REGULATED DIFFERENTIAL LOCK REGULATED REAR AXLE DIFFERENTIAL LOCK RELAY ENERGIZED SERVO MOTOR (UNDER CENTER OF LUGGAGE COMPT FLOOR) WHT/GRY WIRE YEL/WHT WIRE

Go to component -> Rear axle circuit -> NCA WIRE

Wiring diagram nca (74 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (74 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BATTERY BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE CAR ACCESS SYSTEM (LOWER LEFT CENTER OF DASH) CHARGING CIRCUIT CLUTCH MODULE SWITCH (M/T) (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE (RIGHT REAR ENGINE COMPT) DOUBLE CLUTCH TRANSMISSION (7 SPEED A/T) ELECTRONIC TRANSMISSION CONTROL (8 SPEED A/T) (RIGHT REAR OF TRANSMISSION) FUSE BOX (RIGHT SIDE OF DASH) GRN WIRE HOT AT ALL TIMES JUMP START TERMINAL POINT (LEFT SIDE OF ENGINE COMPT) JUNCTION NCA WIRE ORG/ WIRE PT CAN H PT CAN L RED WIRE RED/WHT WIRE SAFETY BATTERY TERMINAL GENERATOR (RIGHT SIDE OF REAR COMPT) START-STOP BUTTON STARTER TRANSFER TERMINAL POINT VIO WIRE W/ AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Starting circuit -> NCA WIRE

Wiring diagram nca (75 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (75 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

AIR BAG IND LAMP BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/ORG WIRE COMBOX COMPUTER DATA LINES SYSTEM CRASH SAFETY MODULE (RIGHT SIDE OF DASH) DRIVER'S AIR BAG INFLATOR ASSEMBLIES (PART OF STEERING WHEEL) DRIVER'S KNEE AIR BAG INFLATOR ASSEMBLY (UNDER LEFT SIDE OF DASH) FUSE FUSE 56 GRN WIRE GRN/BLU WIRE GRY/BLK WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ JUNCTION BOX (RIGHT SIDE OF DASH) NCA WIRE ORG/GRN WIRE PASSENGER'S AIR BAG INFLATOR ASSEMBLIES (TOP RIGHT SIDE OF DASH) PASSENGER'S KNEE AIR BAG INFLATOR ASSEMBLY POWER DISTRIBUTION SYSTEM RED WIRE RED/BRN WIRE RED/YEL WIRE RELAY ENERGIZED ROOF FUNCTION CENTER STEERING COLUMN SWITCH CLUSTER TELEMATIC COMMUNICATION BOX VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE W/ COMBOX W/ TELEMATIC COMMUNICATION BOX WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit (1 of 3) -> NCA WIRE

Wiring diagram nca (76 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (76 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/ORG WIRE GRN/BLU WIRE GRY/BRN WIRE INTEGRATED CHASSIS MANAGEMENT (UNDER CENTER CONSOLE) NCA WIRE VIO/GRY WIRE W/ QUADRUPLE-DRILLED WIRING WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit (2 of 3) -> NCA WIRE

Wiring diagram nca (77 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (77 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER FUSE 120 FUSE 121 REAR COMPT) FUSE 200 GRN WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL INFOTAINMENT FAN LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT FRONT WOOFER LEFT REAR MID- RANGE SPEAKER 2 LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER LEFT REAR TWEETER 2 MOST DATA BUS CIRCUIT NCA WIRE POWER DISTRIBUTION SYSTEM REAR FUSE HOLDER (RIGHT SIDE OF RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT FRONT WOOFER RIGHT REAR MID- RANGE SPEAKER 2 RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER RIGHT REAR TWEETER 2 TOP HIFI AMPLIFIER VIO/BRN WIRE VIO/RED WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Top hifi radio circuit, except premium without active sound design -> NCA WIRE

Wiring diagram nca (78 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (78 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

ACTIVE SOUND DESIGN BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES FUSE BOX (UNDER SPARE TIRE) FUSE LEFT FRONT TWEETER LEFT REAR TWEETER 2 MOST DATA BUS CIRCUIT NCA WIRE PREMIUM TOP HIFI AMPLIFIER RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT TWEETER RIGHT REAR TWEETER 2 VIO/BLK WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Top hifi radio circuit, premium (1 of 3) -> NCA WIRE

Wiring diagram nca (79 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (79 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE ELECTRONICS EXTENDABLE DASHBOARD SPEAKER FUSE FUSE 27 GRY/BLK WIRE GRY/WHT WIRE HOT W/ JUNCTION BOX (RIGHT SIDE OF DASH) LEFT REAR TWEETER MID-RANGE SPEAKER NCA WIRE REAR FUSE HOLDER FUSE (RIGHT SIDE OF REAR COMPT) RED/BLK WIRE RED/BRN WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT REAR TWEETER SEDAN TWEETER SPEAKER VIO/BLK WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE YEL/RED WIRE

Go to component -> Top hifi radio circuit, premium (2 of 3) -> NCA WIRE

Wiring diagram nca (80 of 82)

Wiring diagram nca for BMW M5 F10 facelift (2013-2016) (80 of 82)

Get lifetime access to BMW M5 F10 facelift (2013-2016)

1 2 MOST DATA BUS CIRCUIT BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM NAVIGATION SYSTEM DVD CHANGER (LEFT SIDE OF REAR COMPT) ELECTRONIC NIGHT VISION MODULE (IF EQUIPPED) FUSE 125 FUSE 121 GRN WIRE GRY WIRE HEAD UNIT HOT W/ TERMINAL LOCK OUT CIRCUIT REAR SEAT ENTERTAINMENT NAVIGATION SYSTEM NCA WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE RED/GRN WIRE RED/VIO WIRE SEDAN TV AERIAL 2 VIDEO MODULE (SEDAN: LEFT SIDE OF REAR COMPT) VIDEO SWITCH (IF EQUIPPED) W/ HIGH VERSION W/ OMNIDIRECTIONAL CAMERA, NIGHT VISION CAMERA W/ OMNIDIRECTIONAL CAMERA, W/O NIGHT VISION CAMERA W/ VIDEO SWITCH W/O OMNIDIRECTIONAL CAMERA W/O VIDEO SWITCH W/O VIDEO W/ VIDEO SWITCH SWITCH WHT WIRE YEL WIRE

Go to component -> Video system circuit -> NCA WIRE
