BMW M5 F10 facelift (2013-2016) mirror fold- Wiring diagram
This page shows the only wiring diagram for the component.mirror fold-, which is found in the car BMW M5 F10 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror fold- (1 of 1)
ADJUSTMENT DRIVE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/WHT WIRE
BUS SIG
BUS SIG FOOTWELL MODULE (LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH BLOCK
FUSE 66
GRN WIRE
IN DRIVE
JUNCTION BOX (RIGHT SIDE OF DASH)
LEFT EXTERIOR MIRROR
MIRROR FOLD-
MIRROR FOLD- IN DRIVE
MIRROR HEATER
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR CAMERA
RED/GRY WIRE
RELAY ENERGIZED
RIGHT EXTERIOR MIRROR
WHT/BRN WIRE
WHT/BRN/YEL WIRE
Go to component -> Memory mirrors circuit, with lin bus function -> MIRROR FOLD-
