BMW M5 F10 facelift (2013-2016) mass flow Wiring diagram
This page shows the only wiring diagram for the component.mass flow, which is found in the car BMW M5 F10 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mass flow (1 of 1)
ACT TANK
ACT VALVE
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRY WIRE
CAMSHAFT
CAN BUS SIG
DIGITAL MOTOR ELECTRONICS 2
EXHAUST
FUEL TANK VENT VALVE 2
INTAKE SPLY
MASS AIR FLOW SENSOR 2
MASS FLOW
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
SENS SIG
SENS SPLY
SPLY VALVE
TEMP
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.4l turbo (11 of 12) -> MASS FLOW
