BMW M5 F10 facelift (2013-2016) integrated chassis management Wiring diagram
This page shows the only wiring diagram for the component.integrated chassis management, which is found in the car BMW M5 F10 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram integrated chassis management (1 of 1)
3.0L TURBO DIESEL
ACTIVE STEERING SERVO MOTOR SHIELD
AIR SUPPLY SYSTEM
AUTOMATIC AIR RECIRCULATION CONTROL (AUC) SENSOR
BASIC VARIANT ROOF FUNCTIONS MODULE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CENTER CONSOLE OPERATING UNIT
CENTER REAR SEAT BELT BUCKLE CONTACT
CENTRAL GATEWAY MODULE
CRASH SAFETY MODULE
DIAGNOSIS SOCKET
DRIVER'S SEAT BELT BUCKLE CONTACT
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
ELECTRONIC RIDE HEIGHT CONTROL
EXTERIOR BOOT LID BUTTON
FOOTWELL MODULE
HIGH VARIANT ROOF FUNCTIONS MODULE
HOTEL POSITION SWITCH
INTEGRATED CHASSIS MANAGEMENT
LEFT INNER TAIL- LIGHT
LEFT RIGHT INNER INNER TAIL LIGHT TAIL LIGHT
LICENSE PLATE LIGHT REAR LID W/ REAR LOCK 2 LID BUTTON
NCA WIRE
ORG/ WIRE
PARKING BRAKE CONTROL UNIT
PARKING DISTANCE CONTROL
PARKING MANEUVERING ASSISTANT
PASSENGER'S SEAT BELT BUCKLE CONTACT
PASSENGER'S SEAT OCCUPANCY DEACTIVATION SENSOR
PREMIUM TOP HIFI AMPLIFIER
REAR COMPARTMENT AUC SWITCH SENSOR DISPLAY 2
REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT INNER TAIL LIGHT
SEDAN
SIREN W/ TILT ACTIVE ALARM TANK SENSOR DOSING FUEL LINE LEVEL HEATING SENSOR
W/ AUTOMATIC SOFT CLOSE SYSTEM
W/ BASIC VARIANT
W/ HIGH VARIANT
W/O AUTOMATIC SOFT CLOSE SYSTEM
WASHER FLUID LEVEL BOOT LID SWITCH LIFT
Go to component -> Ground distribution circuit (4 of 6) -> INTEGRATED CHASSIS MANAGEMENT
