Car Wiring Diagrams for Trunk & fuel door release circuit for BMW M5 E60/E61 (2004-2010)

AUTOMATIC TRUNK LID TRUNK LID BUTTON (INTERIOR) AUTOMATIC TRUNK LID/TAILGATE HYDRAULIC PUMP (LEFT SIDE OF REAR COMPT) BASIC BODY MODULE (BEHIND GLOVE BOX) BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FRONT FUSE HOLDER (UNDER RIGHT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES FUSE HOT W/ NCA WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) REAR LID RELEASE SWITCH (INTERIOR) RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED FUSE SEDAN TRUNK LID LIFT MODULE (IF EQUIPPED W/ WAGON) (UNDER SPARE TIRE) TRUNK LID/TAILGATE LOCK SWITCH (SEDAN) VIO WIRE WAGON WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

2) TRUNK LID OPEN (SEDAN) AUTOMATIC SOFT-CLOSE RELAY BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE EXTERIOR TRUNK LID/ BUTTON GRY WIRE GRY/BRN WIRE GRY/YEL WIRE LEFT LUGGAGE COMPARTMENT LIGHT (WAGON) LUGGAGE COMPARTMENT LIGHT (SEDAN) NCA WIRE NOISE SUPPRESSOR FILTER (RIGHT REAR OF ROOF) RED WIRE RED/BRN WIRE RIGHT LUGGAGE COMPARTMENT LIGHT (WAGON) TRUNK LID CENTRAL LOCKING DRIVE W/ TRUNK LID CONTACT SWITCH 1) TRUNK LID CLOSED TRUNK LID/TAILGATE AUTOMATIC SOFT- CLOSE DRIVE (WAGON) (CENTER OF REAR COMPT) TRUNK LID/TAILGATE LUGGAGE COMPARTMENT LIGHT WHT WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
