BMW M5 E60/E61 (2004-2010) oil level switch (right side Wiring diagram

This page shows the only wiring diagram for the component.oil level switch (right side, which is found in the car BMW M5 E60/E61 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram oil level switch (right side (1 of 1)

Wiring diagram oil level switch (right side for BMW M5 E60/E61 (2004-2010)

Get access

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT/YEL WIRE COMPUTER DATA LINES SYSTEM DYNAMIC DRIVE VALVE BLOCK (BEHIND RIGHT FRONT WHEEL) FUSE NCA WIRE OF ENGINE COMPT) OIL LEVEL SWITCH (RIGHT SIDE REAR FUSE HOLDER RED WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Dynamic drive suspension circuit -> OIL LEVEL SWITCH (RIGHT SIDE
