BMW M5 E60/E61 (2004-2010) driver's seat seat occupancy electronics Wiring diagram
This page shows the only wiring diagram for the component.driver's seat seat occupancy electronics, which is found in the car BMW M5 E60/E61 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat seat occupancy electronics (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG INFLATOR ASSEMBLIES
DRIVER'S SEAT SEAT OCCUPANCY ELECTRONICS
FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
JUMP
LEFT ROLLOVER PROTECTION ACTUATOR
NCA WIRE
PASSENGER AIR BAG DEACTIVATION INDICATOR LAMP
PASSENGER'S SEAT OCCUPANCY DETECTION
PASSENGER'S SIDE HEAD AIR BAG INFLATOR ASSEMBLY
PASSENGER'S SIDE REAR SEAT BELT TENSIONER GENERATOR
REAR FUSE HOLDER
RED WIRE
RED/BLU/YEL WIRE
RIGHT ROLLOVER PROTECTION ACTUATOR
ROLLOVER PROTECTION CONTROLLER (CONVERTIBLE)
SAFETY BATTERY TERMINAL GENERATOR
STEERING COLUMN SWITCH CLUSTER
TERMINAL POINT
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> DRIVER'S SEAT SEAT OCCUPANCY ELECTRONICS
