BMW M5 E60/E61 (2004-2010) cooler box Wiring diagram

This page shows the only wiring diagram for the component.cooler box, which is found in the car BMW M5 E60/E61 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram cooler box (1 of 1)

Wiring diagram cooler box for BMW M5 E60/E61 (2004-2010)

Get access

BASIC BODY MODULE (BEHIND GLOVE BOX) BRN WIRE COOLER BOX FRONT INTERIOR LIGHT GRY/RED WIRE LUGGAGE COMPARTMENT LIGHT REAR COMPARTMENT INTERIOR LIGHT (5 SERIES) RED/YEL WIRE TRUNK LID/TAILGATE LUGGAGE COMPARTMENT LIGHT (5 SERIES) YEL WIRE

Go to component: -> Cool box circuit -> COOLER BOX
