BMW M5 E60/E61 (2004-2010) button for electrically operated towing hitch Wiring diagram

This page shows the only wiring diagram for the component.button for electrically operated towing hitch, which is found in the car BMW M5 E60/E61 (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram button for electrically operated towing hitch (1 of 1)

Wiring diagram button for electrically operated towing hitch for BMW M5 E60/E61 (2004-2010)

Get access

BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BUTTON FOR ELECTRICALLY OPERATED TOWING HITCH DRIVE UNIT FOR TOWING HITCH ELECTRICALLY OPERATED TOWING HITCH FUSE 62 FUSE 80 FUSE 85 HOLDER (RIGHT SIDE OF REAR COMPT) GRN WIRE GRN/BLU WIRE HOT AT ALL TIMES HOT W/ TERM HOT W/ TERM 15 RELAY ENERGIZED REAR FUSE RED WIRE RED/BLU WIRE RED/GRY WIRE TRAILER MODULE (UNDER SPARE TIRE) TRAILER SOCKET WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component: -> Active bodyworks circuit -> BUTTON FOR ELECTRICALLY OPERATED TOWING HITCH
