BMW M4 G82 (2020-2024) windshield panel sensor system Wiring diagram

This page shows the only wiring diagram for the component.windshield panel sensor system, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram windshield panel sensor system (1 of 1)

Wiring diagram windshield panel sensor system for BMW M4 G82 (2020-2024)

Get access

BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN WIRE COWL PANEL LOCKED HALL EFFECT SENSOR FUSE 226 FUSE 258 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL LEFT CONVERTIBLE TOP LOCKED, CLOSED HALL EFFECT SENSOR OPEN SOFT TOP COMPARTMENT LID HALL EFFECT SENSOR REAR POWER DISTRIBUTION BOX RED WIRE RED/GRN WIRE RED/YEL WIRE RIGHT CLOSED CONVERTIBLE TOP COMPARTMENT LID HALL EFFECT SENSOR SOFT TOP DRIVE TOP DRIVE UNIT RELAY WINDSHIELD PANEL SENSOR SYSTEM WINDSHIELD PANEL UNLOCKED HALL EFFECT SENSOR YEL WIRE

Go to component: -> Convertible top circuit (2 of 3) -> WINDSHIELD PANEL SENSOR SYSTEM
