BMW M4 G82 (2020-2024) oxygen sensor after catalytic converter 2 Wiring diagram
This page shows the only wiring diagram for the component.oxygen sensor after catalytic converter 2, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oxygen sensor after catalytic converter 2 (1 of 1)
BLK WIRE
BLK/RED WIRE
BRN WIRE
DIGITAL MOTOR ELECTRONICS (LEFT SIDE OF ENGINE COMPT)
EXHAUST CAMSHAFT SENSOR
GRN WIRE
GRY WIRE
INTAKE CAMSHAFT SENSOR
MAP THERMOSTAT
NCA WIRE
OXYGEN SENSOR AFTER CATALYTIC CONVERTER 2
OXYGEN SENSOR BEFORE CATALYTIC CONVERTER 2
POSITION SENSOR
QUANTITY CONTROL VALVE 2
RED WIRE
RED/GRN WIRE
VALVETRONIC SERVOMOTOR (FRONT OF INTAKE MANIFOLD)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Wiring diagram engine performance 3.0l turbo (2 of 7) -> OXYGEN SENSOR AFTER CATALYTIC CONVERTER 2
