BMW M4 G82 (2020-2024) kafas camera heating Wiring diagram
This page shows the only wiring diagram for the component.kafas camera heating, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram kafas camera heating (1 of 1)
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
COMPUTER DATA LINES SYSTEM
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 76
GRN WIRE
GRN/BLK WIRE
HOT W/ TERMINAL
KAFAS CAMERA HEATING
LANE CHANGE WARNING LED
MIRROR ELECTRONICS
RED/BLK WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
Go to component: -> Lane departure warning circuit -> KAFAS CAMERA HEATING
