BMW M4 G82 (2020-2024) gearbox oil temperature sensor Wiring diagram

This page shows the only wiring diagram for the component.gearbox oil temperature sensor, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram gearbox oil temperature sensor (1 of 1)

Wiring diagram gearbox oil temperature sensor for BMW M4 G82 (2020-2024)

Get access

BLU WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE FUSE 209 FUSE 291 GEARBOX OIL TEMPERATURE SENSOR GRN WIRE GRN/RED WIRE HOT W/ NCA WIRE PNK/BLU WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE REGULATED DIFFERENTIAL LOCK REGULATED DIFFERENTIAL LOCK SERVO MOTOR RELAY ENERGIZED YEL WIRE

Go to component: -> Rear axle circuit -> GEARBOX OIL TEMPERATURE SENSOR
